a Computer to Computer link connecting TXD to RXD and RXD to TXD.

With correctly named signals you end up with: Other manufacturers reverse this labeling, making it challenging to figure out the device’s signals. Devices such as modems have a DSR as an output and use the DTR as a counter. The documentation is often sketchy and you may need to use your deductive powers by looking at the device’s other signals. Note: At times it can be difficult to identify the type of device in question. Depending on the type of device, input or output wires can use the same signal.

Signal labels can be deceiving so be careful.

The next step in performing a serial cable test is to connect the device’s input line to the computer’s TXD.

The documentation that comes with the device might guide you in finding this wire.

Next, connect the wire that carries the device’s output data signal to the computer’s RXD.

First, you need to connect the ground, RXD, and TXD wires.

Rewiring the cable connector is another option that more technically proficient users might attempt. Specify a file name at the prompt so you can reload the session later to work with it further.ĭTE equipment may require you to use a null-modem adapter to conduct a serial port test. Alternately you can use the CTRL+S keyboard shortcut or “Save” on the main toolbar.

You save a session with the “Session > Save session/Save session As” option from the app’s main menu.

A new monitoring window is opened using the visualizers previously selected.

Select the capture options from these choices: Create/Close, Read/Write, and Device Control.Ĭlick the “Start monitoring” button to start the new session after all the options have been set. You can control how a new monitoring session begins with the “Start monitoring now” and “Start in new window” checkboxes.

■ Table view employs a table format to present the recorded IRPs.

■ Modbus view displays received and sent Modbus data and support both the RTU and ASCII variation of the protocol.

■ Terminal view uses an ASCII text console to display the data that is received through a line.

■ Dump view displays all sent and received data transmitted through a serial line.

■ Line view concentrates on a specific serial line and provides detailed information regarding any requests it receives.

Choose how the session’s data will be displayed by selecting from among these visualizers:.

The “New monitoring session” window will be displayed.

Clicking “New” on the main toolbar or using “CTRL+N” are alternative methods of starting a session.

Choose “Session > New session” from the main menu.

How to check serial port communication with Serial Port Testerįollow these steps to initiate a new testing session after you have defined the settings for the connection.
